The FMR5 Underground Service Vehicle is designed for light-duty transport and support operations in underground mining environments. Based on a reliable mining chassis platform, the vehicle provides stable performance, strong maneuverability, and safety in confined underground spaces.
| Number of seats | 5 |
| Model | FMR5 |
| Rated load（kg) | 1200kg |
| Power（kw） | Perkins 1104D-E44T 74.5 kW / 2200 rpm |
| Machine weight（kg） | 4200 |
| Speed（km/h） | In first gear 10 km/h In second gear 25km/h |
| Max thrust (kN) | 23kN |
| Min turning radius inside(mm) | 3030mm |
| Min turning radius outer(mm) | 5790mm |
| torque converter | Danfoss H1 |
| Main bridge | DANA212/112 |
| Brake system | Spring braking hydraulic release |
| Dimensions：Length(mm)*Width(mm)*Height(mm) | 4.594mm×2.060mm×1980mm |
| Product Features | Spring suspension on four wheels, cylinder damping and shock absorption |
